Magnetic Damper Features：

A. characteristics of magnetic damper

1. The magnetic damper and name tension controller, tension control or brake, is a constant torque transmission medium of the magnetic field of the device.

Damping disk with magnets, no sliding friction without contact, the service life is long, tension control extremely stable.

2. Installation simple structure, the output torque is convenient adjustment.

3. Structure compact design, small size, can be in all sorts of steady work position.

B. Magnetic damper adjustment methods and use the matters needing attention

1. Recommends that customers will scale value transferred to use 4 or above, if this time tension too large, had better choose a smaller size specifications of damper.

2. If in scale value below 4, may have used the pulse of the force. Please click HouXiang 3 stated way eliminate pulse.

3. Loosen screw, will turn to 10, turn the scale axis at the same time slow will scale turn to 0, and then turn to

Scale needed to tighten lock screw, value.

4. If use appeared in the process of tension, please repeat the above phenomenon pulsation adjustment method 3 steps until the satisfied tension.

5. Damper magnet produce media magnetic field, use material, the use of large brittle do not open it, lest attaint parts.
