characteristic：
For enameled wire or silk thread adequate guidance, the porcelain ring the precision ceramics production, groove ultra precision polishing lidar Ra0.2. Ceramic ring matched with high-speed bearing, on both sides of the baffle can prevent coiling enameled wire jump out of the groove, and the winding tension line remains stable and consistent. Also directly by the full ceramic and high speed bearing combination of ceramic ceramic wheel. Over line parts for various types of winding machines and textile machines.
|
型號 Model |
中間配導輪 Wheel |
大外徑 Large OD |
厚度 Thickness |
軸桿 Shaft |
|
Anti jumper wire wheels od30 |
20*3 |
30 |
10 |
3mm |
|
Anti jumper wire wheels od38 |
28.7*4 |
38 |
13 |
4 or 5mm |
|
Anti jumper wire wheels od50 |
40*4 |
50 |
25 |
4 or 5mm |
|
Anti jumper wire wheels od60 |
47*5 |
60 |
22 |
5 or 6mm |
